Yagi Antenna

Features
  • Linear polarization
  • 900 MHz ISM band (FCC, ETSI, KCC, CCC & etc.)
  • Light weight
  • Long distance recognition performance

Specification


Antenna Gain Table

No. Part Name Antenna Weight
[g]		 Dimension
W×D×H [mm]		 Center Frequency
[MHz]		 Band Width @-10dB
[MHz] typ.		 Hor. Beam Width @-3dB
[deg.] typ.		 Ver. Beam Width @-3dB
[deg.] typ.		 Linear @Center Freq.
[dBiL] typ.
1 MYA80S-915 16 80×80×1 FCC
ETSI
KCC
CCC
&
etc.		 25 75 100 5.0
2 MYA100S-915 20 100×100×1 35 75 100 6.0
3 MYA125S-915 30 125×125×1 80 65 100 7.0
4 MYA1618S-915 60 180×163×1 50 62 95 7.6
5 MYA3018S-915 110 180×300×1 70 55 74 9.8



Antenna Recognition Distance

Reader Power : 30dBm

No. Part Name Dimension
W×D×H [mm]		 Card Tag [m] Alien Tag [m]
Typ. Best Typ. Best
1 MYA80S-915 80×80×1 5.0 6.4 5.2 6.6
2 MYA100S-915 100×100×1 5.8 7.4 7.8 8.0
3 MYA125S-915 125×125×1 6.9 7.8 8.0 8.4
4 MYA1618S-915 180×163×1 8.0 8.4 8.8 9.0
5 MYA3018S-915 180×300×1 8.7 9.0 9.7 10.2
